QR Series Silent Roller Linear Guideway
Key Features
Provides the high rigidity of roller-type linear guideways and uses SynchMotion TM technology with a roller synchronizer to reduce operating noise.
Low-noise design
3 dB
Radial rigidity up to
5,412 N/µm
Static load capacity up to
572 KN
Applications
HIWIN Technical Support
Linear Guideways · QR Series Silent Roller Linear Guideway
Technical Description and Selection ReferenceProduct Overview
The QR Series silent roller linear guideway is a product of the HIWIN linear guideway series. It provides the high rigidity of roller-type linear guideways and uses SynchMotion TM technology with a roller synchronizer to reduce operating noise.
Product Features
- Provides the high rigidity of roller-type linear guideways and uses SynchMotion TM technology with a roller synchronizer to reduce operating noise.
Low-noise design
3 dB
Radial rigidity up to
5,412 N/µm
Static load capacity up to
572 KN
Applications
The QR Series silent roller linear guideway is widely used in CNC machining centers, heavy-duty cutting machines, CNC grinding machines, injection molding machines, large gantry machine tools and other applications, meeting the requirements for stability and precision in precision transmission, automated production and industrial upgrading.
About HIWIN Technologies
HIWIN Technologies (HIWIN) is a global leader in transmission control products and system technology, dedicated to the R&D and manufacturing of precision ball screws, ball splines, linear guideways, single-axis and multi-axis robots, harmonic drives, torque motors and other products, providing high-precision, high-rigidity transmission solutions for the semiconductor, flat panel, machine tool, automation equipment and industrial machinery industries.
Frequently Asked Questions
A linear guideway (linear rail with recirculating ball carriages) provides much higher rigidity, load capacity and accuracy than a ball bushing. Linear Guideways from HIWIN are the industry standard for CNC machines, semiconductor equipment and precision automation.
The QR Series Silent Roller Linear Guideway is available in accuracy grades from C to H (and ultra-precision UP), with preload classes from light (Z0) to heavy (Z3). We help you select the right combination for stiffness, smoothness and travel accuracy.
Mounting requires a clean, flat reference surface with correct torque on the mounting bolts, and alignment by straightedge or laser. Lubricate the carriage rails regularly with the recommended grease; our Linear Guideways with self-lubricating blocks and wipers reduce maintenance needs.
Linear guideways can run at very high speeds; our QR series silent roller guideways reduce noise and vibration for high-speed applications. The QR Series Silent Roller Linear Guideway can achieve high speeds with smooth, quiet motion thanks to optimized ball recirculation.
Yes. We supply Linear Guideways rails cut to your exact length with drilled mounting holes, and carriages preloaded as matched sets for consistent motion and longer service life. OEM/ODM customization is welcome.
Standard models are available in small quantities with shipment within 15 days. Volume and custom orders receive factory-direct pricing — send us the QR Series Silent Roller Linear Guideway model, rail length and quantity for a quotation.
